| Size/Weight |
| Dimensions |
Width |
1,461 mm (57-1/2") |
| Height |
927 mm (36-1/2") |
| Depth |
459 mm (18-1/16") |
| Weight |
Weight |
56.0 kg (123 lbs., 7 oz.) |
| Packing Box |
Width |
1,571 mm (61-7/8") |
| Height |
639 mm (25-3/16") |
| Depth |
569 mm (22-3/8") |
| Control Interface |
| Keyboard |
Number of Keys |
88 |
| Type |
GH3 keyboard with synthetic ebony and ivory keytops |
| Touch Response |
Hard2/Hard1/Medium/Soft1/Soft2/Fixed |
| Pedal |
Number of Pedals |
3: Damper (with half-pedal function), Sostenuto, Soft |
| Functions |
Sustain (Switch), Sustain Continuously, Sostenuto, Soft, Expression, Pitch Bend Up, Pitch Bend Down, Rotary Speed, Vibe Rotor, Song Play/Pause |
| Display |
Type |
Full Dots LCD |
| Size |
128 x 64 dot |
| Language |
English |
| Panel |
Language |
English |
| Cabinet |
| Key Cover |
Key Cover Style |
Sliding |
| Music Rest |
Yes |
| Music Clips |
- |
| Voices |
| Tone Generation |
Piano Sound |
Yamaha CFX |
| Key-off Samples |
Yes |
| Smooth Release |
Yes |
| Virtual Resonance Modeling (VRM) |
Yes |
| Virtual Resonance Modeling Lite (VRM Lite) |
- |
| Polyphony |
Number of Polyphony (Max.) |
256 |
| Preset |
Number of Voices |
24 |
| Effects |
| Types |
Reverb |
6 |
| Chorus |
3 |
| Brilliance |
7 |
| Master Effect |
11 |
| Intelligent Acoustic Control (IAC) |
Yes |
| Stereophonic Optimizer |
Yes |
| Functions |
Dual/Layers |
Yes |
| Split |
Yes |
| Duo |
Yes |
| Songs |
| Preset |
Number of Preset Songs |
14 voice demo songs + 50 classics |
| Recording |
Number of Songs |
250 |
| Number of Tracks |
16 |
| Data Capacity |
Approx. 500 KB/Song |
| Compatible Data Format |
Playback |
SMF (Format 0, Format 1) |
| Recording |
SMF (Format 0) |
| Functions |
| Piano Room |
Yes |
| Overall Controls |
Metronome |
Yes |
| Tempo Range |
5 ‒ 500 |
| Transpose |
-12 ‒ 0 ‒ +12 |
| Tuning |
414.8 - 440.0 - 466.8 Hz (approx. 0.2 Hz increments) |
| Scale Type |
7 |
| Rhythm |
20 |
| Storage and Connectivity |
| Storage |
Internal Memory |
Total maximum size approx. 1.5 MB |
| External Drives |
USB flash drive |
| Connectivity |
Headphones |
Standard stereo phone jack (x 2) |
| MIDI |
[IN] [OUT] [THRU] |
| AUX IN |
Stereo Mini |
| AUX OUT |
[L/L+R] [R] |
| USB TO DEVICE |
Yes |
| USB TO HOST |
Yes |
| DC IN |
16 V |
| Amplifiers and Speakers |
| Amplifiers |
30 W x 2 |
| Speakers |
16 cm x 2 |
| Power Supply |
| Power Consumption |
20 W (When using PA-300C AC adaptor) |
| Auto Power Off |
Yes |
| Power Supply |
Adaptors |
PA-300C |
| Accessories |
| Accessories |
Owner's Manual, 50 Classical Music Masterpieces Music Book, Online Member Product Registration, Warranty*, Bench*, Power cord*/AC adaptor* PA-300C *varies by area |
