Seria QL

Quintessential Compact

Renumita serie CL a ridicat performanța consolei de mixare digitală live la un nivel de rafinament fără precedent, cu o calitate a sunetului, operabilitate și funcționalitate evoluate, menținând în același timp valorile tradiționale care au stabilit standardele industriei mixerelor digitale Yamaha. Caracteristicile de bază și performanța moștenite direct de la seria CL, inclusiv sunetul natural susținut de capacitățile de procesare internă superbe din punct de vedere sonor, funcționarea care se adaptează cu ușurință la cerințele aproape oricărui mediu de lucru și rețeaua Dante încorporată care facilitează configurarea flexibilă a sistemului, au fost condensate și concentrate în consolele de mixare digitale, compacte din seria QL. Consolele din seria QL oferă capacitate all-in-one de mixare, procesare și rutare pentru sunet live la scară mică și medie, evenimente corporative, instalări și multe altele.

Keys to Live Sound Success

Main Features

Pure, Natural Sound Plus Powerful Built-in Processing for Broad Creative Control

Pure, Natural Sound Plus Powerful Built-in Processing for Broad Creative Control

The Yamaha sound begins with reproduction that is faithful to the source. QL series consoles feature circuitry and components that have been designed and selected with the utmost care, achieving outstanding audio purity from input to output. With that solid sonic foundation it becomes possible to take full advantage of built-in premium internal processors such as the Portico 5033/5043 created in cooperation with Rupert Neve, to shape and create as required. For a wide range of speech applications built-in automatic mixing functionality from Dan Dugan Sound Design provides optimum channel balance while allowing the operator to concentrate fully on optimizing the overall sound.

Refined Control for Smooth Operation

Refined Control for Smooth Operation

The ability to respond swiftly and surely to multiple, rapidly changing demands is essential for effective live sound support. QL series consoles feature large touch-panel displays as well as “Touch and Turn” knobs that make up a remarkably smooth, efficient control interface. Attention has also been paid to details such as fader feel and channel name display visibility in order to deliver a sophisticated overall operating experience. Remote control and offline setup capability via an iPad or computer adds even more refinement to an already state-of-the-art operating environment.

Expandable All-in-One Support for Any Application

Expandable All-in-One Support for Any Application

In addition to ample analog input and output capacity, QL series consoles feature the same Dante audio networking protocol that provides broad connectivity in the CL consoles. There's also an innovative “Port to Port” feature that can patch any input port to any output port so the QL console can function as a remote I/O device for any other QL or CL series console, for example. Other flexibility enhancing features such as 2-track and multitrack recording capability, and dual MY expansion slots that allow processing capability or I/O to be added as required, make the QL consoles suitable for use as central components in an extensive variety of sound applications.

Related Applications

Features you can depend on for unsurpassed control and realibility, plus sound that delivers every show with maximum sonic impact.

Broadcast applications demand a great deal of the equipment used in terms of features, adaptability, sound, and reliability. That’s why you’ll find Yamaha professional sound gear in broadcast studios and vehicles around the world.

QL5 Digital Mixing Console

32 + 2 fader configuration adapts to a wide range of channel layouts. The QL5 is a compact console with large-scale capabilities.

  • Mix channels: 64 mono, 8 stereo.
  • Busses: 16 mix, 8 matrix (Input to Matrix supported).
  • Local I/O: 32 in, 16 out.
  • Fader configuration: 32 + 2 (Master).
  • Stainless steel iPad support stays.

QL1 Digital Mixing Console

16 + 2 fader configuration in a compact, rack mountable unit.

  • Mix channels: 32 mono, 8 stereo.
  • Busses: 16 mix, 8 matrix (Input to Matrix supported).
  • Local I/O: 16 in, 8 out.
  • Fader configuration: 16 + 2 (Master).
  • Rack mountable with optional RK1 Rack Mount Kit.

Rio3224-D2 I/O Rack

This high-capacity, high-performance I/O rack is compatible with Yamaha CL and QL series consoles as well as the RIVAGE PM series. It features 32 analog inputs, 16 analog outputs, and eight digital AES/EBU outputs. The Rio3224-D2 connects directly to Dante digital audio networks, allowing flexible system configuration. Dual power supply units are built in for high reliability, and a character/graphic display offers easy visual confirmation.

  • 32 analog inputs and 16 outputs, and 8 digital outputs.
  • Redundant connections are supported with primary and secondary connectors. Daisy chain connections are also supported.
  • Comprehensive display and local control of gain and other parameters.
  • Dual power supply units are built in for high reliability.
  • Power consumption: 120W
  • Dimensions (WxHxD): 480 x 220 x 368mm (18.9" x 8.7" x 14.5")
  • Net Weight: 13.5 kg (29.8 lbs)

Rio1608-D2 I/O Rack

This high-performance I/O rack features 16 analog inputs and 8 analog outputs, and is compatible with Yamaha CL and QL series consoles as well as the RIVAGE PM series. The Rio1608-D2 connects directly to Dante digital audio networks, allowing flexible system configuration. Dual power supply units are built in for high reliability, and a character/graphic display offers easy visual confirmation.

  • 16 analog inputs and 8 outputs.
  • Redundant connections are supported with primary and secondary connectors. Daisy chain connections are also supported.
  • Comprehensive display and local control of gain and other parameters.
  • Dual power supply units are built in for high reliability.
  • Power consumption: 72W
  • Dimensions (WxHxD): 480 x 132 x 368mm (18.9" x 5.2" x 14.5")
  • Net Weight: 9.6 kg (21.2 lbs)

RSio64-D I/O Rack

The RSio64-D is an audio interface that can convert between Dante and Mini-YGDAI formats for up to 64 inputs and 64 outputs

RMio64-D I/O Rack

The RMio64-D Dante/MADI conversion I/O rack is here. It supports a wide range of broadcast and live sound applications with extraordinary flexibility, and without getting in the way.

Ri8-D Input Rack

The 1U size Ri8-D has 8 ins.

Ro8-D Jack de ieșire Discontinuu

The 1U size Ro8-D has 8 outs.

Mini-YGDAI Cards

MY (Mini-YGDAI) series expansion cards for use in the option I/O slots of digital mixers and DME. 3rd-party cards also available.

LA1L

LED Gooseneck Console Lamp.

RK1 Rack Mount Kit

  • Rack mount kit for QL1/LS9-16/DM100VCM/01V96i
